Specifications
- 12.1″ TFT Color LCD Display
- Multilanguage Interface (GB, IT, FR, DE, ES, PT, NL, PL, CZ, TR, RO, RU)
- Adult/Pediatric/Neonate Measurement Modes
- 8 Channel Waveform Synchronous Display
- 7 Lead ECG Waveform On One Screen
- Anti-Motion, Anti-Ambient Light Interference Digital SpO2 Technology
- AC/DC Rechargeable Lithium Battery
- Data Saving Up To 72 Hours In The Internal Memory
- Up To 150 Minutes Use With A Battery Removable And Rechargeable
- Manual/AUTO/Continuous NIBP Measurement Mode
- Standard/OXY- Graph/Trend-Graph/Big Characters And View Bed Interfaces
Technical Specifications:
-
ECG
5-Lead, Dual Channel, 3-Lead, Single Channel
ST Segment Monitoring
| Scan Speed | 12.5 Mm/S, 50 Mm/S |
| Measurement And Alarm Range | -2.0 MV ±2.0 MV• RESP |
| Method | R-F (RA-LL) Impedance |
| Measurement And Alarm Range | 0-150 Rpm |
| Apnea Alarm | 10-40 Sec• NIBP – Oscillometer Method |
| Mode | Manual/AUTO/Continuous |
| Measurement Interval In AUTO Mode | 1/2/3/4/5/10/15/30/60/90/120/240/480/960 Min |
| Measurement Period In CONT Mode | 5 Min |
| Measurement Alarm | 10-270 MmHg• SpO2 |
| Measurement And Alarm Range | 0-100% |
| Measurement Accuracy | 70-100% ±2%• PR |
| Measurement And Alarm Range | 30-250 Bpm |
-
TEMP
| Channel | Dual Channel |
| Measurement And Alarm Range | 0-50 °C |
| Power Supply | 110-240 V – 50/60 Hz |
| Safety Classification | Class I Type CF |
Standard Accessories
- Adult SpO2 Probe
- NIBP Adult Cuff And Extension Tube
- Temperature Probe – Skin
- Rechargeable Lithium Battery
- ECG Cable
- Power Supply Cable
- Manual (GB, IT, ES) On Request (PT, TR)
- ECG Electrodes
